Unit Display Board

Currently, I'm working on a status display board for my job, just a fun lil side project. We have to test units before we ship them out, so we throw them on our building's roof and monitor them for a couple weeks. I got tired of having to check on each one manually, I wanted a board that could show what units are where, and the status of them. One "slot" has two 4-digit 7-segment displays, and three leds; green, yellow, and red. The displays show the main unit's ID, and the auxilliary unit's ID. The led's correspond to the unit's log; whether there are no warnings / errors, warnings, or errors.
